BANDKNIFE SPLITTING MACHINE(VACUUM CONVEYOR TYPE)
SM-690B

APPLICATION:
EVA,PE,RUBBER,SBR,NBR,CR,EPDM,etc... foam Splitting.

Characteristics:
*Automatic reciprocating and forward splitting Saves transfer time of raw material. Increases productivity.
*Automatically thickness adjusting PLC controls every splitting. Only leave 3mm on the table save labor than traditional loop splitting (transfer time).
*Only need one person for operation (collecting finished products). Save labor (a traditional type of needs one person to feed raw material block and two people to collect products).

FEATURES:
* Friendly PLC inter-face, computer touch screes.Easy to operate.
* Thickness controlled and re-located by PLC.
* The position of blade controlled and re-located by PLC.
* Automatic Sliced Piece Counting Function.
* Dusty collector for blade sharpener.
*Close tolerance: +/- 0.05mm  (When starting with level material)

  • Specifications
  • Video
  • Consumables
Model Working width (mm)

Power (HP)

Splitting Speed (M/Hr) Max. Material Thickness (mm) Splitting Hardness (Shore C) Material Transfer Concept

Material

Min. Splitting Thickness (mm)

Tolerance (mm) Splitting Concept
SM-690C 1600 35 600-2400 200 Below 50 Conveyor

EVA, PE, PVC, RUBBER, CR, SBR, EPDM and similar material

0.5 +/- 0.1

Splitting thin sheet 0.2mm

Measure thickness 0.2mm

SM-682 AMS(Automatic Material Stocking)


Part No. Name Picture
689E10 Blade Table Pusher Set(For 1.6M)

689E100

Band-knife

689F416

GRINDSTONE
689F110 Diamond dresser Set For Grinding Wheel
689E30 Blade locator Pusher(Set)
