FEATURES:
* Automatic band-knife adjustment:
* An electric sensor monitors the front edge position of the blade and automatically moved forward to maintain the correct position as the blade gets Narrower through grinding.
* Band-knife is continuos sharpened while Splitting.
* Motorized height adjustment of the upper and bottom Feeding Roller regulate to the layer thickness.
* Dusty collector for blade sharpener.
* Close tolerance:+/-0.1mm When starting with level material.
* Automatic band-knife adjustment: An electric sensor monitors the front edge position of the blade and automatically moved forward to maintain the correct position as the blade gets Narrower through grinding.
- Specifications
- Video
Model | Working width (mm) |
Power (HP) |
Max. Material Thickness (mm) | Splitting Hardness (Shore C) |
Material |
Min. Splitting Thickness (mm) |
Tolerance (mm) | Splitting Concept |
---|---|---|---|---|---|---|---|---|
SM-6105 | 500 | 16 | 50 Above: 25 Below: 25 |
70~90 |
Rubber Slab, Neoliter, Rigid EVA, PVC Flooring mat, Rubber Floor Tiles, etc... |
0.5 (Depending on material) | +/- 0.1 | |
SM-613 | 1300 | 16 | 50 Above: 25 Below: 25 |
Below 60 |
EVA, PE, SBR, CR, EPDM, etc... |
0.5 (Depending on material) | +/- 0.1 | |
SM-613-2WD | 1300 | 16 | 50 Above: 25 Below: 25 |
70~90 |
Rubber Slab, Neoliter, Rigid EVA, PVC Flooring mat, Rubber Floor Tiles, etc... |
0.5 (Depending on material) | +/- 0.1 | |
SM-613H | 1300 | 16 | 145 Above: 45 Below: 100 |
10~75 |
EVA, PE, SBR, CR, EPDM, etc... |
0.5 (Depending on material) | +/- 0.1 | |
SM-616 | 1600 | 16 | 50 Above: 25 Below: 25 |
Below 60 |
EVA, PE, SBR, CR, EPDM, etc... |
0.5 (Depending on material) | +/- 0.1 | |
SM-616-2WD | 1600 | 16 | 50 Above: 25 Below: 25 |
70~90 |
Rubber Slab, Neoliter, Rigid EVA, PVC Flooring mat, Rubber Floor Tiles, etc... |
0.5 (Depending on material) | +/- 0.1 | |
SM-616H | 1600 | 16 | 145 Above: 45 Below: 100 |
10~75 |
EVA, PE, SBR, CR, EPDM, etc... |
0.5 (Depending on material) | +/- 0.1 |
Rubber Floor Tiles Splittied with SM-613-2WD
